As part of my ongoing research I have been developing a receiver structure. I moved it to C++ for speed after initial experiments using Matlab. Part of the receiver structure includes lowpass and bandpass signal filters that were still using coefficient values printed from a Matlab designed filter using the fir1 command.

I now need to tweak the filter parameters (order and cut frequency) at run-time based on command-line arguments as part of performance analysis experiments. The filter types I am using are fairly straightforward Lowpass and Bandpass Windowed-Sinc filters. So it seems reasonable to be able to reproduce the filter coefficients generator in C++.

TL;DR For the eager, the code for doing just that can be found at the bottom of this post.

For an overview of Sinc Filter and Windows have a look at the wikipedia pages.

However, there is a great web page that provides an accessible and comprehensive explanation of Sinc Filters and Windows at labbookpages.co.uk. This is where the equations and approach for the sourcecode below was derived.

Once the filter weights were calculated they required normalising to give unity gain at the desired frequency. This same challenge was faced and answered on stack exchange. However, a more in-depth overview of FIR properties can be viewed at dpsguru.com.

The output of the example program below produces the filter coefficients for a Lowpass 4th order 4kHz filter (with sampling frequency of 48kHz). It also produces filter coefficients for a Bandpass 8th order 8kHz to 16kHz filter (with sampling frequency of 48kHz).

If the code below is useful please do drop me a line and let me know. Likewise if you discover any bugs. 🙂

PS. The namespace enum technique comes from this stackexchange answer.

[code light=”true”]
\$ ./test.exe
FilterFactory example usage

Lowpass Filter: order=4 fSampling=48000Hz fCut=4000Hz
coefficients=[0.0305778, 0.23833, 0.462183, 0.23833, 0.0305778]

Bandpass Filter: order=8 fSampling=48000Hz fCutLow=8000Hz fCutHigh=16000Hz
coefficients=[0.0168833, -1.28162e-017, -0.227925, 0, 0.510383, 0, -0.227925, -1.28162e-017, 0.0168833]
[/code]

Sourcecode follows:

[code language=”cpp” collapse=”true” title=”main.cpp”]
//——————————————————————————
//
// Copyright (c) 2015 Benjamin Sherlock
//
// Permission is hereby granted, free of charge, to any person obtaining a copy
// of this software and associated documentation files (the "Software"), to deal
// in the Software without restriction, including without limitation the rights
// to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
// copies of the Software, and to permit persons to whom the Software is
// furnished to do so, subject to the following conditions:
//
// The above copyright notice and this permission notice shall be included in
// all copies or substantial portions of the Software.
//
// THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
// IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
// FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
// AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
// LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
// OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
// THE SOFTWARE.
//——————————————————————————
//
// main.cpp
//
//——————————————————————————
//
// This has been tested using cygwin and x86_64-w64-mingw32-g++.
//
// Compile: g++ main.cpp FilterFactory.cpp -o test.exe -lm -static
// Run: ./test.exe
//
//——————————————————————————

// Includes
#include "config.h"

#include <iostream>
#include "FilterFactory.h"

//! Main Function
int main(int argc, char** argv)
{
std::cout << "FilterFactory example usage" << std::endl << std::endl;

// Create a FilterFactory
FilterFactory filterFactory;

// Filter order – must be even number.
int order = 4;

// Sample Frequency
Float fSampling = 48000.0;

// Cut frequency
Float fCut = 4000.0;

// Create Filter
FilterHolderType lowpassFilter = filterFactory.createFilter(
order, FilterWindowType::HAMMING, FilterType::LOWPASS,
fSampling, fCut);

// Output details
std::cout << "Lowpass Filter: order=" << order
<< " fSampling=" << fSampling
<< "Hz fCut=" << fCut << "Hz" << std::endl;

std::cout << "coefficients=[";
for(int n = 0; n < lowpassFilter.coefficients.size(); n++)
{
std::cout << lowpassFilter.coefficients[n];

if( n < (lowpassFilter.coefficients.size()-1) )
{
std::cout << ", ";
}
}
std::cout << "]" << std::endl << std::endl;

// Filter order – must be even number.
order = 8;

// Sample Frequency
fSampling = 48000.0;

// Cut frequencies
Float fCutLow = 8000.0;
Float fCutHigh = 16000.0;

// Create Filter
FilterHolderType bandpassFilter = filterFactory.createFilter(
order, FilterWindowType::HAMMING, FilterType::BANDPASS,
fSampling, fCutLow, fCutHigh);

// Output details
std::cout << "Bandpass Filter: order=" << order
<< " fSampling=" << fSampling
<< "Hz fCutLow=" << fCutLow
<< "Hz fCutHigh=" << fCutHigh << "Hz" << std::endl;

std::cout << "coefficients=[";
for(int n = 0; n < bandpassFilter.coefficients.size(); n++)
{
std::cout << bandpassFilter.coefficients[n];

if( n < (bandpassFilter.coefficients.size()-1) )
{
std::cout << ", ";
}
}
std::cout << "]" << std::endl << std::endl;

return 0;
}

[/code]

[code language=”cpp” collapse=”true” title=”config.h”]
//——————————————————————————
//
// Copyright (c) 2015 Benjamin Sherlock
//
// Permission is hereby granted, free of charge, to any person obtaining a copy
// of this software and associated documentation files (the "Software"), to deal
// in the Software without restriction, including without limitation the rights
// to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
// copies of the Software, and to permit persons to whom the Software is
// furnished to do so, subject to the following conditions:
//
// The above copyright notice and this permission notice shall be included in
// all copies or substantial portions of the Software.
//
// THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
// IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
// FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
// AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
// LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
// OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
// THE SOFTWARE.
//——————————————————————————
//
// config.h
//
//——————————————————————————

#ifndef CONFIG_H
#define CONFIG_H

// Select single or double precision floats
#define USE_FLOAT (0)

#if USE_FLOAT
typedef float Float;
#else
typedef double Float;
#endif

#endif
[/code]

[code language=”cpp” collapse=”true” title=”FilterFactory.h”]
//——————————————————————————
//
// Copyright (c) 2015 Benjamin Sherlock
//
// Permission is hereby granted, free of charge, to any person obtaining a copy
// of this software and associated documentation files (the "Software"), to deal
// in the Software without restriction, including without limitation the rights
// to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
// copies of the Software, and to permit persons to whom the Software is
// furnished to do so, subject to the following conditions:
//
// The above copyright notice and this permission notice shall be included in
// all copies or substantial portions of the Software.
//
// THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
// IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
// FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
// AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
// LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
// OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
// THE SOFTWARE.
//——————————————————————————
//
// FilterFactory.h
//
//——————————————————————————
//
// Matlab fir1 function is a "Window-based FIR filter design" tool.
// Windowed-Sinc Filters
//
// http://www.labbookpages.co.uk/audio/firWindowing.html
// https://en.wikipedia.org/wiki/Window_function#Hamming_window
//
//——————————————————————————

#ifndef FILTERFACTORY_H
#define FILTERFACTORY_H

// Includes
#include "config.h"

#include <vector>
//#include

//! Window Type enum container
struct FilterWindowType
{
typedef enum
{
RECTANGULAR = 0,
BARTLETT,
HANNING,
HAMMING,
BLACKMAN
} Type;
};

//! Filter Type enum container
struct FilterType
{
typedef enum
{
LOWPASS = 0,
HIGHPASS,
BANDPASS,
BANDSTOP,
ALLPASS
} Type;
};

//! Filter Properites Holder struct
struct FilterHolderType
{
int order;
std::vector<Float> coefficients;
};

//! Filter Factory class
class FilterFactory
{
public:
//! Constructor
FilterFactory();

//! Destructor
virtual ~FilterFactory() {}

//! Create Filter
FilterHolderType createFilter(int order,
FilterWindowType::Type windowType, FilterType::Type filterType,
Float Fs = 0, Float Fc1 = 0, Float Fc2 = 0);

//! Create Window Weights
std::vector<Float> createWindowWeights(int order,
FilterWindowType::Type windowType);

//! Create Sinc Weights
std::vector<Float> createSincWeights(int order,
FilterType::Type filterType,
Float Fs = 0, Float Fc1 = 0, Float Fc2 = 0);

//! Create Filter Weights – Combines Sinc and Window Weights
std::vector<Float> createFilterWeights(int order,
FilterWindowType::Type windowType, FilterType::Type filterType,
Float Fs = 0, Float Fc1 = 0, Float Fc2 = 0);

protected:

private:

};

#endif // FILTERFACTORY_H

[/code]

[code language=”cpp” collapse=”true” title=”FilterFactory.cpp”]
//——————————————————————————
//
// Copyright (c) 2015 Benjamin Sherlock
//
// Permission is hereby granted, free of charge, to any person obtaining a copy
// of this software and associated documentation files (the "Software"), to deal
// in the Software without restriction, including without limitation the rights
// to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
// copies of the Software, and to permit persons to whom the Software is
// furnished to do so, subject to the following conditions:
//
// The above copyright notice and this permission notice shall be included in
// all copies or substantial portions of the Software.
//
// THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
// IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
// FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
// AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
// LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
// OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN
// THE SOFTWARE.
//——————————————————————————
//
// FilterFactory.cpp
//
//——————————————————————————

// Includes
#include "config.h"

#include <cmath>
#include <vector>
#include "FilterFactory.h"

//! Constructor
FilterFactory::FilterFactory()
{
}

//! Create Filter
FilterHolderType FilterFactory::createFilter(int order,
FilterWindowType::Type windowType, FilterType::Type filterType,
Float Fs /* = 0 */, Float Fc1 /* = 0 */, Float Fc2 /* = 0 */)
{
FilterHolderType filterHolder;

filterHolder.order = order;
filterHolder.coefficients = createFilterWeights(order, windowType,
filterType, Fs, Fc1, Fc2);

return filterHolder;
}

//! Create Window Weights
std::vector<Float> FilterFactory::createWindowWeights(int order,
FilterWindowType::Type windowType)
{
// Equations from http://www.labbookpages.co.uk/audio/firWindowing.html
// where M is the order
switch( windowType )
{
case FilterWindowType::RECTANGULAR:
{
// w(n) = 1
std::vector<Float> window(order+1, 1.0);
return window;
break;
}

case FilterWindowType::BARTLETT:
{
// w(n) = 1 – 2|n-M/2|/M
std::vector<Float> window(order+1);

for( int n = 0; n < (order+1); n++ )
{
window[n] = 1.0
– (2.0 * fabs( (Float)(n – (order/2)) ) / (Float)order);
}

return window;
break;
}

case FilterWindowType::HANNING:
{
// w(n) = 0.5 – 0.5cos(2*PI*n/M)
std::vector<Float> window(order+1);

for( int n = 0; n < (order+1); n++ )
{
window[n] = 0.5
– 0.5 * cos( 2.0 * M_PI * ((Float)n / (Float)order) );
}

return window;
break;
}

case FilterWindowType::HAMMING:
{
// w(n) = 0.54 – 0.46cos(2*PI*n/M)
std::vector<Float> window(order+1);

for( int n = 0; n < (order+1); n++ )
{
// Approximation lowers levels of sidelobes – as used in matlab
window[n] = 0.54
– 0.46 * cos( 2.0 * M_PI * ((Float)n / (Float)order) );

// Actual value?
//window[n] = (25.0/46.0)
//- (21.0/46.0) * cos( 2.0 * M_PI * ((Float)n / (Float)order) );

// Approximation to create equirriple?
//window[n] = 0.53836
//- 0.46164 * cos( 2.0 * M_PI * ((Float)n / (Float)order) );
}

return window;
break;
}

case FilterWindowType::BLACKMAN:
{
// w(n) = 0.42 – 0.5cos(2*PI*n/M) + 0.08cos(4*PI*n/M)
std::vector<Float> window(order+1);

for( int n = 0; n < (order+1); n++ )
{
window[n] = 0.42
– 0.5 * cos( 2.0 * M_PI * ((Float)n / (Float)order) )
+ 0.08 * cos( 4.0 * M_PI * ((Float)n / (Float)order) );
}

return window;
break;
}

default:
{
// w(n) = 1 – rectangular
std::vector<Float> window(order+1, 1.0);

return window;
break;
}

}
}

//! Create Sinc Weights
std::vector<Float> FilterFactory::createSincWeights(int order,
FilterType::Type filterType,
Float Fs /* = 0 */, Float Fc1 /* = 0 */, Float Fc2 /* = 0 */)
{
switch( filterType )
{
case FilterType::LOWPASS:
{
Float Ft = Fc1 / Fs;
std::vector<Float> weights(order+1, 0.0);

for( int n = 0; n < (order+1); n++ )
{
if( n == (order/2) )
{
// Centre
weights[n] = 2.0 * Ft;
}
else
{
weights[n] = sin( 2.0 * M_PI * Ft * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)));
}
}

return weights;
break;
}

case FilterType::HIGHPASS:
{
Float Ft = Fc1 / Fs;
std::vector<Float> weights(order+1, 0.0);

for( int n = 0; n < (order+1); n++ )
{
if( n == (order/2) )
{
// Centre
weights[n] = 1.0 – (2.0 * Ft);
}
else
{
weights[n] = -1.0
* sin( 2.0 * M_PI * Ft * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)));
}
}

return weights;
break;
}

case FilterType::BANDPASS:
{
Float Ft1 = Fc1 / Fs;
Float Ft2 = Fc2 / Fs;
std::vector<Float> weights(order+1, 0.0);

for( int n = 0; n < (order+1); n++ )
{
if( n == (order/2) )
{
// Centre
weights[n] = 2.0 * (Ft2 – Ft1);
}
else
{
weights[n] = sin( 2.0 * M_PI * Ft2 * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)))
– sin( 2.0 * M_PI * Ft1 * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)));
}
}

return weights;
break;
}

case FilterType::BANDSTOP:
{
Float Ft1 = Fc1 / Fs;
Float Ft2 = Fc2 / Fs;
std::vector<Float> weights(order+1, 0.0);

for( int n = 0; n < (order+1); n++ )
{
if( n == (order/2) )
{
// Centre
weights[n] = 1.0 – (2.0 * (Ft2 – Ft1));
}
else
{
weights[n] = sin( 2.0 * M_PI * Ft1 * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)))
– sin( 2.0 * M_PI * Ft2 * (Float)(n – (order/2)) )
/ (M_PI * (Float)(n – (order/2)));
}
}

return weights;
break;
}

case FilterType::ALLPASS:
{
// w(n) = 0 except at M/2 where w(n) = 1
std::vector<Float> weights(order+1, 0.0);
weights[order/2] = 1.0;
return weights;
break;
}

default:
{
// w(n) = 0 except at M/2 where w(n) = 1
std::vector<Float> weights(order+1, 0.0);
weights[order/2] = 1.0;
return weights;
break;
}
}
}

//! Create Filter Weights – Combines Sinc and Window Weights
std::vector<Float> FilterFactory::createFilterWeights(int order,
FilterWindowType::Type windowType, FilterType::Type filterType,
Float Fs /* = 0 */, Float Fc1 /* = 0 */, Float Fc2 /* = 0 */)
{
std::vector<Float> window = createWindowWeights(order, windowType);
std::vector<Float> weights = createSincWeights(order, filterType,
Fs, Fc1, Fc2);

// Now multiply window weights with sinc weights.
for( int n = 0; n < (order+1); n++ )
{
weights[n] = window[n] * weights[n];
}

// Now normalise for constant gain at a specific frequency
// http://dsp.stackexchange.com/questions/4693/fir-filter-gain
// http://dspguru.com/dsp/faqs/fir/properties

// H(jw) is frequency response (so calculate complex gain for a given frequency then take magnitude).

Float FtSelected = 0.0;

switch( filterType )
{
case FilterType::LOWPASS:
case FilterType::BANDSTOP:
{
/*
// Simplified version to calculate gain at DC.
for( int n = 0; n < (order+1); n++ )
{
gain = gain + weights[n];
}
*/

FtSelected = 0.0; // DC

break;
}

case FilterType::HIGHPASS:
{
// Select frequency above the cut frequency
FtSelected = 0.499; // Just below Nyquist

break;
}

case FilterType::BANDPASS:
{
// Select mid-frequency of the pass band
Float Ft1 = Fc1 / Fs;
Float Ft2 = Fc2 / Fs;
FtSelected = (Ft1 + Ft2) / 2.0;

break;
}
}

// Calculate the frequency response’s complex gain for the given frequency.
Float gainReal = 0.0;
Float gainImag = 0.0;

for( int n = 0; n < (order+1); n++ )
{
gainReal = gainReal + weights[n]
* cos( 2.0 * M_PI * FtSelected * (Float)(n – (order/2)) );

gainImag = gainImag – weights[n]
* sin( 2.0 * M_PI * FtSelected * (Float)(n – (order/2)) );
}

// Get the magnitude of the complex gain.
Float gain = sqrt( gainReal * gainReal + gainImag * gainImag );

// Now divide weights by the gain magnitude.
for( int n = 0; n < (order+1); n++ )
{
weights[n] = weights[n] / gain;
}

return weights;
}

[/code]
